Samsung Galaxy Tab 7.7
-
Display: 7.7 inches, 800 x 1280 pixels, Super AMOLED Plus
-
Chipset: Exynos 4210
-
RAM: 1GB
-
OS: Android 3.2 (Honeycomb), upgradable to Android 4.1 (Jelly Bean)
-
Battery: 5100 mAh
-
Released Date: 01-12-2011
Specifications
General
| Device Type | Android Tablet |
| Model | Samsung Galaxy Tab 7.7 - (as known as Samsung P6800) |
| Released | December, 2011 |
| Status | Discontinued |
Design
| Dimensions | 196.7 x 133 x 7.9 mm |
| Weight | 340g |
| Colors | Black |
Display
| Display Type Display Technology => A number of display technologies and types used in mobile phones => TFT (Thin Film Transistor), IPS (In-Place Switching), OLED (Organic Light Emitting Diode), AMOLED (Active-Matrix Organic Light-Emitting Diode), Super AMOLED (an even advanced version of AMOLED), Resistive Touchscreen (Resistive touchscreens contain two layer of conductive material with a very small gap between them which acts as a resistance), Capacitive Touchsceen (Capacitive touchscreen technology consists of a layer of glass coated with a transparent conductor) | Super AMOLED Plus |
| Size | 7.7 inches |
| Resolution | 800 x 1280 pixels |
| Pixel Density Pixel Density (PPI) is refers to the concentration of pixels on a particular display, measured in pixels per inch (ppi). Pixel density is calculated by dividing the diagonal pixel resolution of a display by its diagonal size, higher pixel density better display quality. | ~196 ppi |
Platform
| Operating System OS => Every computer system run on a base software called Operating System (OS). Operating System controls all basic operations of the computer (such as smartphone, PDAs, tablet computers and other handheld devices). The Operating System allows the user to install and run third party applications (apps), apps are used to add new functionality to the device. | Android 3.2 (Honeycomb), upgradable to Android 4.1 (Jelly Bean) |
| SIM SIM (Subscriber Identity Module) is a small card that contains mobile network subscriber's account information. This allows the phone using the card to attach to a mobile network. The SIM card is most commonly associated with GSM and UMTS mobile networks. Moving a SIM card from one phone to another allows a subscriber to switch mobile phones without having to contact their mobile network carrier. SIM cards can also be used by a phone to store limited amounts of data, such as phone numbers and text messages. | Mini-SIM |
Hardware
| Chipset Chipset is a group of integrated circuits designed to perform one or a more dedicated functions, often with real time computing constraints, Popular smartphones are equipped with more advanced embedded chipsets that can do many different tasks depending on their programming. | Exynos 4210 |
| CPU | Dual-core 1.4 GHz Cortex-A9 |
| GPU GPU (Graphics Processing Unit) is a single-chip processor designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display, This includes things such as lighting effects, object transformations, and 3D motion. | Mali-400 |
| RAM RAM (Random Access Memory) is a type of computer memory that can be accessed randomly, any byte of memory can be accessed without touching the preceding bytes that allows information to be stored and accessed quickly from random locations. RAM is the most common type of memory found in computer systems, smartphones, tablets and other electronic devices. | 1GB |
| Internal Storage Internal Storage is a data storage space (flash memory) mostly used in smartphones, tablets and other electronic devices where operating system, apps, music, photos, videos, files and other user data Is stored. | 16GB/32GB/64GB |
| Memory Card Slot Memory Card Slot is a special slot for inserting a memory card. Memory cards allow you to expand the phone's built-in memory, A memory card (sometimes called a flash memory card or a storage card) is a small storage medium used to store data such as text, pictures, audio, and video, for use on small, portable or remote computing devices such as mobile phones, mp3 players, digital cameras. | Yes |
| Sensors Sensors are electronic components that detects and responds to some type of input from the physical environment. The specific input could be light, heat, motion, moisture, pressure and location, The output is generally a signal that is converted to use in computing systems, a location sensor, such as a GPS receiver is able to detect current location of your electronic device. | Accelerometer, gyro, proximity, compass |
| 3.5mm jack | Yes |
| Loudspeaker | Yes, with stereo speakers |
| Audio Technology | DNSe sound enhancement |
Battery
| Capacity Battery Capacity is a measure (typically in Amp-hr) of the charge stored by the battery, and is determined by the mass of active material contained in the battery. The battery capacity represents the maximum amount of energy that can be extracted from the battery under certain conditions. | 5100 mAh |
| Battery Life | Stand-by: Up to 1200 h (2G) / Up to 1100 h (3G) Talk time: Up to 34 h 10 min (2G) / Up to 20 h (3G) |
| Charging | USB Charge Cable |
Camera
| Rear Camera Camera is able to capture photographs and usually videos, The most important characteristics of a camera are the resolution (measured in megapixels), lens focus type (fixed or automatic), higher megapixel cameras are known to capture higher quality photos, but not always a good measurement of the photos quality. | 3.15 |
| Front Camera | 2 MP |
| Video | 720p@30fps |
| Camera Features | LED flash |
| Flash Flash Light => There is commonly two types of flash lights are used in camera mobile phones, LED Flash (LED flash offers lower power consumption with drive circuitry that takes up very little room, LEDs can be strobed faster than any other light source), Xenon Flash (xenon flash produces an extremely intense full-spectrum white light for a very short duration) | Yes |
Connectivity
| Bluetooth Bluetooth is a wireless communications technology for exchanging data between mobile phones, headsets, computers and other network devices over short distances without wires, Bluetooth technology was primarily designed to support simple wireless networking of personal consumer devices. | 3.0 |
| Wi-fi Wi-Fi is a popular wireless networking technology using radio waves to provide high-speed network connections that allows devices to communicate without cords or cables, Wi-Fi is increasingly becoming the preferred mode of internet connectivity all over the world. | Wi-Fi 802.11 a/b/g/n, dual-band, Wi-Fi Direct, hotspot |
| USB | 2.0 (TV-out), OTG |
| GPS GPS The Global Positioning System is a satellite-based radio navigation system, GPS permits users to determine their position, velocity and the time 24 hours a day, in all weather, anywhere in the world, In order to locate your position, your device or GPS receiver must have a clear view of the sky. | Yes |
| NFC NFC (Near field communication) is a set of standards for smartphones and similar devices to establish peer-to-peer radio communications with each other by touching them together or bringing them into proximity, usually no more than a few inches. | |
| Wireless Charging Wireless Charging (Inductive Charging) uses an electromagnetic field to transfer energy between two objects. This is usually done with a charging station. Energy is sent through an inductive coupling to an electrical device, which can then use that energy to charge batteries or run the device. | No |
Reviews
| User Reviews 1 User Reviews |
I particularly like the Super AMOLED Plus display, describing it as the best looking display I've ever seen on a tablet thanks to the deep contrasts, vivid colors, and great quality for reading text. I also really appreciate the lightweight and thin yet sturdy design which makes the tablet highly portable to carry around and fit into my pockets more easily than 10 inch tablets. Additionally, I find the fast 4G LTE connectivity a huge selling point for increased portability. However, I did notice some sluggishness in the user interface and touch response which I attribute to the Android 3.2 operating system. I also think the $499 on-contract pricing seems a bit high. - Mike - DetroitBORG |
| User Reviews 2 |
I think the gorgeous Super AMOLED Plus display is definitely the best thing about this tablet. It has incredibly deep blacks, great viewing angles, and just looks great. It's among the best displays I've seen on an Android tablet. The tablet is also impressively thin and lightweight making it very portable. The LTE connectivity provides fast and consistent data speeds, though not as fast as I expected. Still, battery life remains quite strong with over a day of heavy use. Ultimately though, I think Honeycomb's limitations hold back great hardware. - David |
| User Reviews 3 |
I absolutely love the Super AMOLED Plus display on this tablet. It offers excellent contrast, deep blacks, vibrant colors, and great viewing angles from any angle. It's clearly superior to the Galaxy Tab 7.0 Plus and the best display I've seen on an Android tablet. The metal design also feels more premium than the plastic 7.0 Plus, with a scratch-resistant back that attracts less fingerprints. However, both tablets are still well-built and extremely thin and light. Impressively, the 7.7 packs a large battery delivering over 12 hours of video playback. - Engadget |
| Tabletmonkeys Reviews Tabletmonkeys Reviews |
Pros: - Gorgeous Super AMOLED Plus display with excellent contrast, colors, and viewing angles - Very portable and lightweight thin design - Fast performance with dual-core processor - Long 12+ hour video playback battery life Cons: - Sluggish interface at times due to Android 3.2 - Unexceptional 3MP/2MP camera quality |
Samsung impresses with their 7.7-inch Galaxy Tab that packs a brilliant high-resolution Super AMOLED Plus screen into an incredibly thin and lightweight tablet body. The Galaxy Tab 7.7 stands out in the competitive tablet market by offering the best display we’ve seen yet on an Android device.
Design and Dimensions: Portability Redefined
In the world of tablets, the Samsung Galaxy Tab 7.7 stands out as a visual marvel, primarily owing to its Super AMOLED Plus display.
With dimensions of 196.7 x 133 x 7.9 mm and a weight of 340g, this tablet boasts a sleek and portable design, available in a classic black color. Despite being discontinued, its impact is still felt, and here's a closer look at what makes it special.
Display Brilliance: Super AMOLED Plus in Action
The 7.7-inch Super AMOLED Plus display, with a resolution of 800 x 1280 pixels and a pixel density of 196 ppi, is undoubtedly the star of the show.
Users praise its deep contrasts, vivid colors, and remarkable text readability, making it one of the best displays seen on an Android tablet.
Under the Hood: Power and Performance
Running on Android 3.2 Honeycomb, the tablet is powered by a dual-core 1.4 GHz Cortex-A9 processor, coupled with 1GB of RAM.
While this configuration provides fast performance, some users have reported occasional sluggishness in the user interface, likely due to the aging operating system.
Storage and Sensors: Practical Enhancements
The tablet offers 16GB of internal storage, expandable via a microSDHC dedicated slot. The inclusion of essential sensors like accelerometer, ambient light sensor, compass, gyroscope, and proximity sensor enhances the overall user experience.
Audio Bliss: DNSe Sound Enhancement
The audio experience on the Galaxy Tab 7.7 is enriched with DNSe sound enhancement, complemented by stereo speakers.
The tablet's 3.5mm jack allows users to connect their favorite headphones for an immersive audio experience.
Battery Life: Powering Through
A notable feature is the tablet's impressive battery life. With a non-removable Li-Po 5100 mAh battery, users can enjoy up to 34 hours of talk time and up to 1200 hours of standby time. Wired charging keeps the tablet powered up for continuous use.
Capture the Moment: Camera Capabilities
Photography enthusiasts might find the tablet's camera capabilities satisfactory. The rear camera is a 3 MP shooter with autofocus and LED flash, while the front camera is a 2 MP sensor.
Video recording at 720p@30fps is a decent offering for a tablet of its time.
Connectivity at its Core: Bluetooth, Wi-Fi, and More
Connectivity options include Bluetooth 3.0 and Wi-Fi 802.11 a/b/g/n, providing users with versatile ways to stay connected. The tablet also supports Wi-Fi hotspot functionality for sharing the internet connection.
Performance Concerns: Navigating the Operating System
While the Galaxy Tab 7.7 impresses with its display and design, it does face criticism for the sluggishness attributed to the Honeycomb operating system.
Some users have expressed concerns about the lack of software updates and the potential impact on long-term performance.
Pricing and Verdict: Balancing Act
In terms of pricing, the tablet faced competition challenges, especially with a $499 on-contract pricing that some users deemed steep.
However, those who prioritize portability and display quality found the tablet to be a valuable investment.
Conclusion: A Lasting Impression
In conclusion, the Samsung Galaxy Tab 7.7, despite being discontinued, leaves a lasting impression with its exceptional display technology and portable design.
While some performance concerns exist, it remains a noteworthy device for those seeking a balance between visual appeal and functionality.
